| Description X-axis travel: 1016mm, Y-axis travel: 610mm, Z-axis travel: 760mm, distance from spindle nose to pallet: 150-910mm, distance from spindle axis to column: 635mm, distance from spindle axis to front of machine: 820mm, distance from table to floor: 959mm, working surface dimensions: 1270x590mm, number of T-slots: 5, T-slot width: 18mm, center T-slot dimensions: 18 H6 mm, centering bore diameter: 30 H6 mm, T-slot spacing: 125mm, max. table load: 1350kg, working feed rate: 0-15m/min, max. programmable feed rate: 40m/min, rapid traverse speed: 40m/min, acceleration: 5m/s², max. spindle speed: 10,000rpm, control system: HEIDENHAIN, length: 2750mm, width: 2120mm, height: 2100mm, weight: approx. 7.7t, operational hours counter: approx. 17,000h, including documentation. An on-site inspection is possible. |
|
| Make | Tajmac Zpc S.s. |
|---|---|
| Model | MCFV 1060S |
| Year of manufacture | 2008 |
| Price | On application |
| Offer No | INNO32612 |
