| Description Ink cup/doctor ring diameter: 130mm, cliché size: 150 x 300mm, maximum print image size: 84.5 x 84.5mm, print image diameter: 120mm, cycle rate in continuous operation: 480 cycles/h, cycle rate in start stop operation: 450 cycles/h, pad stroke over cliché: 10 to 100mm, pad stroke over workpiece continuously adjustable: 10 to 180mm, maximum pad installation height: 90 to 115mm, printing force: 2900N, speed control: continuously variable, automation interface: D-SUB 37-pin, service interface: Profinet, air consumption: 130NL per cycle, connected load: 1.2kW, control system: Siemens SIMATIC PANEL, length: 1510mm, width: 1692mm, height: 2205mm, weight: 1.68t. Inspection on site is possible. |
|
| Make | Tampoprint |
|---|---|
| Model | CONCENTRA 130-4 |
| Year of manufacture | unknown |
| Price | On application |
| Offer No | INNO31789 |
