| Description Swing diameter over bed/cross slide: 320mm/150mm, center height: 160mm, distance between centers: 750mm, max. turning length: 740mm, travel X/Z: 185mm/700mm, chuck diameter: 200mm, speed: 4000rpm, rapid traverse X/Z: 5m/10m/min, tool stations: 8, tailstock quill stroke: 120mm, tailstock quill diameter: 60mm, machine dimensions X/Y/Z: approx. 2300mm/1500mm/1700mm, weight: approx. 2000kg, control: Heidenhain. Documentation available. An on-site inspection is possible. |
|
| Make | Gildemeister |
|---|---|
| Model | NEF 320 |
| Year of manufacture | 2003 |
| Price | On application |
| Offer No | INNO31676 |
