| Description Three cable processing machines from a complete extrusion line are available. 1) Spindle pay-off Ka-Be-Ma AS400, spool flange diameter range: 140mm-400mm, min. core diameter: 90mm, max. spool width: 300mm, max. spool weight: 50kg, conductor diameter range: 0.1mm-1mm, max. pay-off speed: 600m/min, tensile force: 0.5N-20N, machine dimensions X/Y/Z: approx. 1200mm/1550mm/1450mm, weight: approx. 1000kg. 2) Cooling section Ka-Be-Ma T-KW-UKW-A-1,5, Zone 1: Process: immersion cooling, temperature range: 70°C-80°C, length: 2000mm. Zone 2: Process: spray cooling/deflection section, temperature: approx. 25°C. 3) Dual take-up Ka-Be-Ma DWST400-1, spool flange diameter range: 305mm-400mm, min. core diameter: 156mm, max. spool width: 282mm, conductor diameter range: 0.1mm-1mm, speed: 600m/min, tensile force range: 0.5N-1.5N, max. spool weight: 80kg, machine dimensions X/Y/Z: approx. 1200mm/1550mm/1450mm, weight: approx. 2200kg. Documentation available. An on-site inspection is possible. |
|
| Make | Ka-be-ma |
|---|---|
| Model | AS400/T-KW-UKW-A-1,5/DWST400-1 |
| Year of manufacture | 2005 |
| Price | On application |
| Offer No | INNO31109 |
