| Description Screw diameter: 40mm, screw stroke: 160mm, displacement volume: 201cm³, shot weight: 184g, injection pressure: 2000bar, shot volume: 168cm³, clamping force: 1500kN, opening force: 350kN, opening stroke: 500mm, min. mold installation height: 250mm, platen distance: 750mm, tie bar distance: 470mm/470mm, platen dimensions X/Y: 650mm/650mm, weight: approx. 5000kg, operating hours: approx. 60000h. Documentation available. An on site inspection is possible. |
|
| Make | Arburg |
|---|---|
| Model | Allrounder 470C 1500/400 |
| Year of manufacture | 2009 |
| Price | On application |
| Offer No | INNO30481 |
