| Description X-axis: 350mm, z-axis: 1000mm, grinding diameter: 290mm, grinding length: 800mm, center height: 150mm, x-axis speed: 0.0001–10m/min, z-axis speed: 0.0001–12m/min, control: CNC Fanuc Oi-TD, connected load: 25kVA, length: 3340mm, width: 2660mm, height: 2325mm, weight: 8t. equipment/accessories: software functions for grinding spline shafts for gear pumps, external grinding cycles: plunge, straight, taper, multiple plunge, straight, taper, oscillation, straight, taper, shoulder plunge, shoulder with K-value, shoulder oscillation, DIN ISO. dressing cycles: dressing of radii as well as concave and convex shapes possible, periphery, left flank, right flank, profiles according to DIN ISO. measuring system: measuring device tec, diameter measuring head measuring range: 1mm, measuring accuracy: 0.5μm, not suitable for measuring an interrupted cut, length measuring head measuring range: -/+2mm, measuring accuracy: 0.5μm, use of two length measuring heads (2 measuring probes). operating hours: approx. 7847h. documentation available. an on-site inspection is possible. |
|
| Make | Junker |
|---|---|
| Model | Lean Selection Allround |
| Year of manufacture | 2014 |
| Price | On application |
| Offer No | INNO28716 |
